Key Features

• Magnetic Sector High-Resolution Analyzer

  • Double-focusing magnetic sector delivering resolution >60,000 (10% valley) and mass accuracy better than 2–5 ppm.

  • Mass scan range: 2 to 6,000 m/z.

  • Linear dynamic range >5 orders of magnitude with scan rates from 0.1 to 10,000 Da/sec.

  • Multiple scanning modes: voltage scan, magnet scan, Multiple Ion Detection (MID/SIM), and Multiple Reaction Monitoring (MRM).

• Unmatched Sensitivity for POPs/Dioxins

  • Achieves signal-to-noise (S/N) ratio ≥ 200:1 (peak-to-peak, 4σ) for 20 fg of 2,3,7,8-TCDD on column.

• Regulatory Compliance and Robust Software Tools

  • Fully compliant with global methods (EPA 1613, 1668, 1614; EU, JIS, etc.) for dioxin, PCB, and PBDE analysis.

  • DFS-specific software: SmartTune™ for optimized tuning and TargetQuan™ for isotope-dilution quantitation.

  • Optional DualData XL module nearly doubles sample throughput.

• Operational Convenience & Stability

  • Constant mass calibration per run using lock-mass ensures reproducible data.

  • Ventless ion source exchange and separable source housing reduce maintenance downtime.

• Compact Footprint & Quiet Operation

  • Compact system with low noise and low power consumption.

  • Integrated vacuum system with turbo-molecular and rotary pumps.

Applications

• Dioxins, PCBs, PBDEs, and other POPs analysis (EPA and EU compliance).

• Environmental testing in soil, water, air, and biological samples.

• High-sensitivity food safety and clinical research.

• Certified data generation for regulatory laboratories.
